Drive Axle for Forklifts

Forklift Drive Axles - The piece of equipment that is elastically fastened to the framework of the vehicle utilizing a lift mast is called the lift truck drive axle. The lift mast affixes to the drive axle and could be inclined, by at least one tilting cylinder, round the axial centerline of the drive axle. Frontward bearing elements together with back bearing components of a torque bearing system are responsible for fastening the vehicle and the drive axle frame. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing components. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the lift truck framework and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented almost parallel to a plane extending from the axial centerline and to the swiveling axis.

Forklift models like for instance H45, H35 and H40 that are manufactured in Aschaffenburg, Germany by Linde AG, have the lift mast tilt ably mounted on the vehicle framework. The drive axle is elastically attached to the lift truck frame utilizing numerous bearing devices. The drive axle comprise tubular axle body along with extension arms affixed to it and extend backwards. This kind of drive axle is elastically affixed to the vehicle frame using back bearing elements on the extension arms together with frontward bearing tools located on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the vehicle from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle are sustained through the rear bearing parts on the framework using the extension arms. The load and the lift mast generate the forces that are transmitted into the street or floor by the framework of the vehicle through the drive axle's anterior bearing elements. It is vital to ensure the components of the drive axle are constructed in a firm enough method to maintain strength of the forklift truck. The bearing parts can reduce slight road surface irregularities or bumps during travel to a limited extent and provide a bit smoother operation.
