Side Tilt Carriages - There are 4 sizes of hook type fork carriages rated by the fork carriage lifting capability. Hook type tine carriages have been the same.
The carriage bar spacing used for Class 1 is approximately thirteen inches and the Class 1 carriage is rated to hold cargo as much as 2000lbs. The Class 2 carriage is rated to hold cargo as much as 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this particular class is 20 inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing used for this capacity is 25 inches.
The carriages for pin type forks may be different depending on the manufacturer. Pin mounted blades could differ by the amount of offset between the fork eye and the blade. Carriage capacity will be determined by the carriage pin size and by the fork size.
